Bibcock
Brass or zinc-alloy body, aluminium handle with red cover
size:1/2", 3/4"
Nozzle Bibcock with Iron Handle
1)code: BT2001
2)size: 1/2"-1"
3)max pressure: 25bar
4)Temp.:-10<t<120
5)suitable medium: water
6)material: brass body , brass ball , steel handle.
Description of product
brass or zinc-alloy body,butterfly handle
Nominal pressure: 0.6MPa
Suitable medium: water
Working temperature: 0≤t≤100°C
Parallel thread conform to ISO-228-1:2000 standard
Components and materials:
Screw: steel
Gasket: steel
Handle: steel (red paint)
Stem: steel (brass coating)
Stem o-ring: NBR
Stem o-ring: NBR
Ball: steel (chromed)
Bonnet: zinc alloy
Body: zinc alloy
Nozzle: brass
Filter: PVC
Size: through 1/2 to 1 inches
Fegular checking on line from production in each workshop, one special inspector inspect the goods in random during the period time of production.
1.Is it in stock
Pls contact us and it according to your detail products model
2.Can you speed up delivery?
If ou produce line is not very busy we can speed up delivery for you
3.Can you supply the sample ?
We can supply the sample if we have stock
4.Do you have agent ?
We haven't agent ,but we have sales central in Spain and Germany
5.Can we to be your agent ?
It according to your purchase qty per year
6.The produce process
Inquire—offer—Invoice—drawing confirm—mass production—SGS Test report confirm–Delivery
