Bronze ball valve
Specification:
1.pressure: 150LB 200LB 300LB
2.Media: sea water, oil, liquefied gas,steam
3.Temperature: water below 120 degree C, oil ,gas ,steam below 220 degree C
4.Tread connection Std: (G ,Rc ,RP) BSP, BSPT ,NPT
Description
Bronze ball valves for use in commercial and light industrial applications. Typical services include; hot and cold domestic water, HVAC, low pressure steam, compressed air, LP gas, natural gas.non-shock water working pressure (WWP), Blowout-proof stem, Chrome plated brass ball and silicon bronze stem, Standard lever handle, with Stainless Steel 316 Ball and Stem, Two Piece, Inline, Lever, Solder End
Two Piece Inline Lever Solder End Bronze Ball Valves
Two Piece Quarter-Turn Bronze Ball Valves
1.CONNECTION TYPE: FXF
2.COMMON BRASS MATERIAL Hpb57-3
3.IRON NUT
4.SURFACE TREATMENT:SAND-BLASTING AND NATURE COLOR IN BODY&THREAD
5.BRAND:AQUA-MIGEN OR OEM
6.THREAD:G BSP NTP
7.HANDLE:IRON HANDLE THROME PLATED ANY COLOR WITH PVC COVER
8.INSET BALL:BRASS
9 PTFE SEATED
10STEM:BRASS
11.FULL PORT
12.PN:16
13.PACKING:PTFE
14.BRASS GLAND NUT ,O-RING
15.long thread
