Product Category

3 piece stainless steel flanged ball valves

3 piece stainless steel flanged ball valves

1)Material: WCB, SS304, 304L, 316, 316L
2)Shell wall thickness, ANSI B16.34
3)Certificate: ISO9001: 2000
4)Pressure-temp. Rating- ANSI B16.34
5)End flanges: ANSI B16.5
6)Butt welding ends-ANSI B16.25
7)Suitable medium: Water, gas, air and some corrosive liquid">

Three Piece Flange Ball Valve
SIZE: 1/2"~12" (ANSI 150 LBS~ANSI 300 LBS)
1)Material: WCB, SS304, 304L, 316, 316L
2)Shell wall thickness, ANSI B16.34
3)Certificate: ISO9001: 2000
4)Pressure-temp. Rating- ANSI B16.34
5)End flanges: ANSI B16.5
6)Butt welding ends-ANSI B16.25
7)Suitable medium: Water, gas, air and some corrosive liquid

Quantity:

Share this:

Inquire Add To Basket

Model: CMECSS4
Brand: AQUA-MIGEN
Code: 8481804090

Product Description
Materials
Standard
FAQ

3PC Flanged Ball Valve
1. Investment Casting Body (1/2"~12")

2. Anti-Blow-Out Stem, Anti-Static Device

3. Adjustable Stem Packing

4. Reinforced 15% GF/Teflon Seals And Seats

5. Temperature Range: -60 to 450° F

6. Fire Safe Designed (Option)

7.100% Leakage Tested At 100 PSI Air Under Water

8. ISO-5211 Mounting Pad For Actuator (Option)

 1.4408 (SS316),

 Face-To-Face Dimensions: DIN 3202 F1

1.Is it in stock

Pls contact us and it according to your detail products model

2.Can you speed up delivery?

If ou produce line is not very busy we can speed up delivery for you

3.Can you supply the sample ?

We can supply the sample if we have stock

4.Do you have agent ?

We haven't agent ,but we have sales central in Spain and Germany

5.Can we to be your agent ?

It according to your purchase qty per year

6.The produce process

Inquire—offer—Invoice—drawing confirm—mass production—SGS Test report confirm–Delivery
